SPARTUS® Easy 1500 laser welding machine with wire feeder
Περιγραφή
SPARTUS® EASY 1500 – INNOVATIVE TECHNOLOGY FOR WELDING, CUTTING AND CLEANING MATERIALS
The SPARTUS® Easy 1500 laser welder is the key to achieving unparalleled quality in connections. This device surpasses traditional welding methods like MIG or TIG due to the exceptional precision it offers. The laser enables the creation of significantly smaller, microscopic-sized welds, thereby minimizing the heat-affected zone on the surrounding material. Consequently, laser welding is an excellent choice for joining even the tiniest components that are challenging to weld using other welding methods.
ADVANTAGES OF SPARTUS® Easy 1500:
- High precision welding
- Excellent control over the welding process
- Limited material distortion
- Clean welds that require no post-processing
- Application in hard-to-reach areas
- Optimized production time
- Durable and resilient joints
- Capability to join, cut, and clean various materials
- High-class laser source
WIRE FEEDER
The wire feeder for the SPARTUS® Easy 1500 laser welder is a device that precisely delivers welding material to the welding area. This is crucial for controlling welding parameters, improving weld quality, and enhancing process efficiency. It automates the wire feeding, allowing the operator to focus on monitoring the welding process. As a result, the wire feeder is a significant tool in laser welding, especially in industrial production.
WELDING MATERIALS
| maximum thickness |
| 5mm
4mm 5mm 4mm 3mm 2mm |
SPARTUS® LASER HEAD F230
The modern laser head allows for focal length adjustment. Additionally, it is equipped with a welding wire feeder mechanism. Ergonomic and user-friendly, it ensures precise and comfortable operation for the operator. Comes with a set of starter nozzles.
As an option, there's the possibility to switch the F210 head.
ONE DEVICE, MULTIPLE FUNCTIONS
SPARTUS® Easy 1500 is not only used for welding but also for cutting and cleaning various materials.
Laser cutting allows for precise material separation, creating accurate and clean edges without the need for mechanical processing. The cutting function as an additional device option allows cutting stainless steel up to 2mm and carbon steel up to 1.5mm. Copper and aluminum, as materials with a high beam reflection coefficient, should not be subjected to the laser cutting process.
Laser cleaning is an effective method for removing contaminants, paint layers, or rust from material surfaces while preserving their integrity and quality. Thanks to these laser technology applications, we achieve exceptional material processing efficiency with minimal impact on their structure.
MULTILINGUAL MENU
The device interface is available in the following languages: • Polish • English • German • French • Spanish • Italian • Czech • Slovak • Greek • Romanian • Portuguese • Korean • Turkish • Russian
